XMZ、XMZQ型全自动压滤机 Automatic filter press
主要适用于悬浮液产品的固液分离，广泛应用于选煤厂煤泥回收，化工厂电石渣、碱泥的脱水及建材、冶金、食品、环保等领域的固液分离。
Such filter presses mainly apply to solid-liquid separation of suspension products. They are widely used for the recycle of coal slime in coal preparation plants, the dewatering of carbide slag and soda mud in chemical plants, as well as solid-liquid separation in fields such as building material, metallurgy, food, and environmental protection.
| 型号规格 Model | 过滤面积 Filtering
area |
滤板尺寸 Filtration plate size |
滤室容积 Area | 滤板数量 (块) | 入料 压力 | 滤室宽度 mm | 功率 Power | 机重 weight |
| m2 | mm | m3 | MPa | kw | t | |||
| XNZ120/1250 | 120 | 1250×1250×65 | 2.1 | 45 | 0.6-0.8 | 35 | 5.5 | 26.1 |
| XMZQ120/1250 | 120 | 1250×1250×65 | 2.1 | 45 | 0.6-0.8 | 35 | 5.5 | 15.1 |
| XMZ150/1250 | 150 | 1250×1250×65 | 2.6 | 56 | 0.6-0.8 | 35 | 5.5 | 28.5 |
| XMZQ150/1250 | 150 | 1250×1250×65 | 2.6 | 56 | 0.6-0.8 | 35 | 5.5 | 19 |
| XMZ200/1250 | 200 | 1250×1250×65 | 3.12 | 75 | 0.6-0.8 | 35 | 5.5 | 38.6 |
| XMZQ200/1250 | 200 | 1250×1250×65 | 3.12 | 75 | 0.6-0.8 | 35 | 5.5 | 19.8 |
| XMZ250/1250 | 250 | 1250×1250×60 | 3.8 | 95 | 0.6-0.8 | 30 | 5.5 | 47.1 |
| XMZQ250/1250 | 250 | 1250×1250×65 | 4.4 | 95 | 0.6-0.8 | 30 | 5.5 | 21.8 |
| XMZ200/1500 | 200 | 1500×1500×65 | 3.2 | 51 | 0.6-0.8 | 35 | 5.5 | 42.9 |
| XMZQ200/1500 | 200 | 1500×1500×70 | 3.05 | 51 | 0.6-0.8 | 30 | 5.5 | 24.6 |
| XMZ300/1500 | 300 | 1500×1500×65 | 4.82 | 82 | 0.6-0.8 | 35 | 5.5 | 51.5 |
| XMZQ300/1500 | 300 | 1500×1500×70 | 4.82 | 82 | 0.6-0.8 | 30 | 5.5 | 27.2 |
| XMZ400/1500 | 400 | 1500×1500×65 | 6.9 | 102 | 0.6-0.8 | 35 | 5.5 | 60.5 |
| XMZQ400/1500 | 400 | 1500×1500×70 | 6.99 | 102 | 0.6-0.8 | 35 | 5.5 | 31.2 |
| XMZ500/1500 | 500 | 1500×1500×70 | 10.2 | 132 | 0.6-0.8 | 40 | 5.5 | 80.8 |
| XMZQ500/1500 | 500 | 1500×1500×70 | 8.9 | 130 | 0.6-0.8 | 35 | 5.5 | 35 |
