ZSW型振动给料机 Linear virating feeder
该给料机系直线振动式给料机，具有振动平稳、工作可靠、寿命长等特点，可为破碎机械连续、均匀喂料，并对物料进料粗筛分，广泛用于选矿、建材、硅酸盐和化学工业中的破碎、筛分联合设备。
This type of linear vibrating feeder is characterized by stable vibration, reliable operation, long service life, etc. It is capable of feeding crushers in an uninterrupted and even way and coarsely sieving materials. Such linear vibrating feeders are widely used in crushing and screening equipment in ore-dressing, building materials, silicate and chemical industry.
| 型号规格Model | 进料料度 Feed size | 处理能力 Capa. | 偏心轴 转速Speed | 功率 Power | 料槽尺寸 | 外形尺寸 Overrall dimensions | 重量 Weight |
| mm | t/h | r/mm | kw | mm | mm | t | |
| ZSW380×95Ⅱ | 500 | 96-160 | 500-714 | 11 | 3800×960 | 3882×2177 ×2066 | 4.1 |
| ZSW420×110 | 580 | 120-240 | 500-800 | 15 | 4200×1100 | 4282×2400 ×2150 | 4.7 |
| ZSW490×96 | 500 | 120-240 | 500-800 | 15 | 4900×960 | 4957×2277 ×2150 | 5.4 |
| ZSW490×110Ⅱ | 630 | 120-280 | 500-800 | 15 | 4900×1100 | 4950×2425 ×2031 | 5.4 |
| ZSW590×110 | 630 | 350 | 750 | 22 | 5900×1100 | 6000×2500 ×2150 | 6.1 |
| ZSW590×130 | 630 | 400 | 750 | 22 | 5900×1300 | 6000×2700 ×2150 | 6.3 |
| ZSW600×130 | 750 | 400-560 | 500-800 | 22 | 6000×1300 | 6082×2580 ×2083 | 7.8 |
