GBH型中型板式给料机Middle-duty slat feeder
CBH中型机输送物料堆积密度不大于2400 kg/m3，块重不超过300kg，温度不高于400℃的各种松散物料。输送板宽一般在500mm-1250mm。
GBH middle-duty slat feeders convey various kinds of bulk materials whose bulk density is not larger than 2,400kg/m3, block weight does not exceed 300kg, and temperature is not higher than 400℃. The widths of conveying board for such feeders are usually 500mm – 1,250mm.
| 型号规格 Model | 链板 | 给料粒度 Feed size | 给料能力 Feed capa. | 外形尺寸 Dimension | 功率 Power | 总重Weight | |
| 宽度 | 轴距 | ||||||
| mm | mm | mm | m³/h | mm | kw | t | |
| GBH80 2.2 | 800 | 2200 | 300 | 15～91 | 3840×2853×1185 | 7.5 | 3.722 |
| GBH80-4 | 800 | 4000 | 300 | 15～91 | 5640×2826×1185 | 7.5 | 4.903 |
| GBH80-15 | 800 | 15000 | ≤300 | 6.5～128 | 17018×4046×1495 | 15/10 | 21.502 |
| GBH100-1.6 | 100 | 1600 | ≤300 | 22～131 | 3240×3026×1235 | 7.5 | 3.561 |
| GBH100-3 | 100 | 3000 | ≤350 | 22～131 | 4640×3114×1235 | 7.5 | 4.548 |
| GBH100-12 | 100 | 12000 | ≤350 | 10～192 | 14018×4246×1495 | 15/10 | 19.405 |
| GBH120-1.8 | 1200 | 1800 | 300-400 | 35～217 | 3440×3313×1285 | 7.5 | 3.965 |
| GBH120-2.2 | 1200 | 2200 | 300-400 | 35～217 | 3840×3314×1285 | 7.5 | 4.238 |
| GBH120-2.6 | 1200 | 2600 | 300-400 | 35～217 | 4240×3313×1285 | 7.5 | 4.572 |
| GBH120-3 | 1200 | 2600 | 300-400 | 35～217 | 4640×3313×1285 | 7.5 | 4.886 |
| GBH120-4 | 1200 | 4000 | 300-400 | 35～217 | 5640×3314×1285 | 7.5 | 5.706 |
| GBH120-4.5 | 1200 | 4500 | ≤350 | 14～289 | 6410×3576×1310 | 11/7.5 | 7.26 |
| GBH120-6 | 1200 | 6000 | ≤400 | 9～63 | 7640×3549×1253 | 7.5 | 8.061 |
| GBH150-4.5 | 1500 | 4500 | ≤350 | 0～421 | 6940×2400×3225 | 7.5 | 20.066 |
| GBH150-7 | 1500 | 7070 | ≤350 | 0～421 | 9910×2400×3225 | 7.5 | 26.008 |
我们要求服务人员时刻关注客户，及时解决设备问题，确保顾客的利益比一切都重要。
