·SKMQR型润磨机 Damp Mill

SKMQR型润磨机 Damp Mill

润磨机是球磨工艺中的主要设备,它处理含水量在8-13%的物料,使物料充分混合和细化,增大物料的比表面积,使用润磨机可以缩短球团矿的制作工艺、降低设备能耗、提高团矿质量和金属回收率、改善劳动条件和环保条件等。润磨机与球磨机的基础上有三个主要差异:强制给料、周边排矿、橡胶衬板。

Damp mills are the main equipment in ball milling technology. They handle materials with water content of 8% to 13% to fully mix and thin materials and increase specific surface area of materials. Damp mills can shorten the fabrication process of pellet ores, reduce energy consumption of equipment, improve the quality of agglomeration and metal recovery rate, as well as improve labor conditions and environmental protection conditions. There are three main differences between the damp mills and ball mills: forced feeding, peripheral discharging, and rubber lining board.

型号规格 单位 SKMQR2745 SKMQR3254 SKMQR3562
图号     K2128 K2129
筒体内径 mm 2700 3200 3500
筒体工作长度 mm 4500 5400 6200
筒体有效容量 m3 23.5 39.5 55.6
****装载量 物料 t 3.8 6 8.7
钢球 t 27.30 44 64
筒体工作转数 r/min 17.86 16.5 15.47
主电动机 型号   YR4503-8 YR5003-8 YTM5602-6
功率 kw 400 630 1000
转速 r/min 735 740 993
电压 v 6000 6000 6000
主减速成器 速比   4.5 4.6 6.74
输入转速 r/min 735 740 993
慢速驱动装置 电机参数   Y160M2-8 5.5KW,380V
730 r/min
Y160L-8 11KW,380V
970 r/min
Y180L-8 11KW,380V
730 r/min
减速机速比   400 500 355
输出转速 r/min 1.8 1.94 2.056
螺旋输料装置 电机功率 kw 11 18.5 18.5
电机电压 v 380 380 380
电机转速 r/min 1500 1000 1000
减速机输出转速 r/min 25.4 23.25 23.25
速比   59 43 43
机器外型尺寸 mm   13400×7250 ×5700 15473×7707 ×6280
机器重量(不含主电机、电控) t 65 122 133
产量 t/h 30 50 70

SKMQR型润磨机 Damp Mill
