·PCY-S型段锤式破碎机 Stage Hammer Crusher

PCY-S型段锤式破碎机 Stage Hammer Crusher

公司生产一段锤式破碎机已有悠久的历史,1980年曾为广西黎塘水泥厂生产的PCY-S2020一段锤式破碎机,获辽宁省科技进步二等奖。公司生产的中、大型一段锤式破碎机具有生产能力高、破碎比大、产品粒度均匀、工艺流程简单等特点,具有双给料辊与单给料辊功能,产品已行成系列,满足了5000t/d水泥生产线以下石灰石破碎的需要。

The company has long been engaged in the production of one-stage hammer crushers. The PCY-S2020 one-stage hammer crusher manufactured by Guangxi Litang Cement Factory in 1980 won the Second Prize of Science and Technology Development for Liaoning Province. The medium-sized and large-sized one-stage hammer crushers manufactured by the company have characteristics such as high productive capacity, big crushing ratio, uniform product particle size, and simple technical flow. They are equipped with double feed rollers and single feed rollers functions. The company has developed a series of such products which meet the requirement of crushing limestone on cement production line of 5,000t/d.

技术参数

型号 转子直径 转子长度 给料粒度 出料粒度 产量 功率 重量
mm mm ≤mm ≤mm t/h kw t
PCY-S1616 1600 1600 800 80 150~250 280 45
PCY-S2020 2000 2000 1100 80 400~600 630 108
PCY-S2030 2000 3000 1500 80 1000~1200 1000 190

PCY-S型段锤式破碎机 Stage Hammer Crusher
