·2MGG型管磨机 Tube Mill

2MGG型管磨机 Tube Mill

管磨机具有生产能力高、对物料适应性强、破碎比大等特点,为满足市场需求,又开发设计与生产制造了多种规格的大型管磨机,具有标准化、通用化、系列化的特点,产品远销国内外, 现已满足日产5000t水泥生产线以下的原料与熟料生产的需要。

have characteristics of high productive capacity, strong adaptability to materials, and big crushing ratio. To meet the need of the market, it designed and manufactured large tube mills of many specifications which are standardized, universalized, and serialized. The products are sold at home and abroad which have now met the requirements of manufacturing 5000 tons of raw materials and clinker on the cement production line.

技术参数

型号规格 水泥 生料 筒体直径 筒体长度 筒体工作转数 传动方式 电机
功率 转速 电压
t/h t/h m m r/min   r/min V
2MGG-B1806 6 8.5 1.83 6.4 23.9 边缘 2kW10 735 380
2MGG-B1807 7.2 10 1.83 7 23.9 边缘 245 735 380
2MGG-Z2206 10~11 18~19 2.2 6.5 20.79 中心/边缘 400 500 6000/10000
2MGG-Z2207 20~27 35~37 2.6 7.9 19.5 边缘 630 167 6000/10000
3MGG-B2610 17~18 27~30 2.6 10 19.5 边缘 630 738 6000/10000
3MG-Z2613 28~29 43~50 2.2 13 21.6 中心/边缘 1000 167 6000/10000
3MGN-Z3009 38   3 9 17.52 中心 1250 742 6000/10000
3MGN-Z3011 33   3 11 17.65 中心 1450 741 6000/10000
3MN-B3012   50 3.0 12 17.6 边缘 800 745 6000/10000
MNG-Z3288   75 3.2 8.8 17.7 边缘 1250 741 6000/10000
MNG-Z3510   80 3.5 10 16.5 中心 1800 743 6000/10000
MNG-Z3511 60~62   3.5 11.5 16.5 中心 2500 740 6000/10000
2MGN-Z3813 65   3.8 13 16.3 中心 2800 742 6000/10000
2MGN-Z4213 75/150   4.2 13 16 中心 3550 742 6000/10000
2MGN-Z5015 160   5 15 14.5 中心 6300 742 6000/10000

2MGG型管磨机Tube Mill
