·KC型侧卸式曲轨矿车 Single side ramp grandy mine car

KC型侧卸式曲轨矿车 Single side ramp grandy mine cars

国家行业标准JB/T9025

本矿车用于井下及地面运输各种矿石、煤炭、建筑材料等。用机车牵引、在卸料点设置卸矿曲轨，能自动卸料。

Such mine cars are used in the pit or on the ground to transport various ores, coal, building materials, etc. They are led by locomotives, set ore unloading bent at the emptying point, and can unload materials automatically.

型号规格Model	容积Volume	装载量Loading weight	轨距Track base	卸载角度Unloading angle	牵引高度Dragging hight	牵引力Dragging force	质量Weight
型号规格Model	m³	t	mm	（°）	mm	KN	t
KC0.7-6	0.7	1.77	600	40	320	60	0.63
KC1.2-6	1.2	3	600	42	320	60	1.03
KC1.6-6	1.6	4	600	42	320	60	1.36
KC2-6	2	5	600	42	320	60	1.9
KC2-7	2	5	762	42	320	60	2
KC2.5-6	2.5	6.25	600	42	320	60	2
KC2.5-7	2.5	6.25	762	42	320	60	2.1
KC4-7	4	10	762	42	430	60	3.2
KC4-9	4	10	900	42	430	60	3.3
YCC0.7-6	0.7	0.75	600	40	320	60	0.75
YCC1-6	1	2.5	600	45	320	60	0.99
YCC1.6-6	1.6	4	600	42	320	60	1.45
YCC2A-6	2	5	600	45	320	60	2.1
YCC2.5-6	2.5	6.4	600	45	320	60	2.45
YCC4-9	4	10	900	42	320	60	3.3
YCC6-7	6	15	762	45	320	60	6.5

KC型侧卸式曲轨矿车 Single side ramp grandy mine cars Series
