MGC、YGC型固定车箱式窄轨矿车 Bottom type narrow gauge mine car

国家行业标准JB/T9027

本矿车适用于煤矿、金属矿山、地下巷道及地表工业场地运输矿石、废石等其他物料。可挂成列用机车牵引、卸料用翻车机进行。

Such mine cars are used in coal mines, metal mines, underworkings and operation site to transport ores, barren rock, and other materials. They can be hung in rows and dragged by locomotives. Materials are unloaded through car dumpers.

型号规格Model	容积Volume	装载量Loading weight	轨距Track base	牵引高度Dragging hight	牵引力Dragging force	外形尺寸 Overrall dimensions	质量Weigh t
型号规格Model	m³	t	mm	mm	KN	m	t
MGC0.5-6	0.5	1	600	320	60	1.3×0.8×1	0.34
MGC0.7-6	0.7	1.75	600	320	60	1.5×0.9×1.1	0.5
MGC1.1-6	1.1	1.8	600	320	60	2×0.9×1.2	0.58
MGC1.2-6	1.2	3	600	320	60	1.9×1.1×1.2	0.75
MGC1.2-7	1.2	3	762	320	60	1.9×1.1×1.2	0.8
MGC1.7-6	1.7	2.7	600	320	60	2.4×1×1.2	0.8
MGC1.7-9	1.7	2.7	900	320	60	2.4×1×1.2	0.9
MGC2-6	2	5	600	320	60	3×1.2×1.2	1.33
MGC2-7	2	5	762	320	60	3×1.2×1.2	1.35
MGC3.3-9	3.3	5.5	900	320	60	3.5×1.4×1.3	1.56
YGC0.5-6	0.5	1.25	600	320	60	2×0.9×1.2	0.61
YGC0.7-6	0.7	1.75	600	320	60	1.5×0.9×1.1	0.65
YGC1.2-6	1.2	3	600	320	60	1.9×1.1×1.2	0.72
YGC2-6	3	5	600	320	60	3×1.2×1.3	1.3
YGC4-7	4	10	762	320	60	3.7×1.3×1.6	1.62
YGC4-9	4	10	900	320	60	3.7×1.3×1.6	1.7
YGC10-7	10	25	762	430	79	7.2×1.5×1.6	7
YGC10-9	10	25	900	430	79	7.2×1.5×1.6	7.1
