JH型回柱绞车 Mine winch
JH系列回柱较车主要用于矿山井下回柱放顶或做水平牵引重物等。绞车电机、电控设备具有隔爆性能。
Series JH Mining hoisting winch is used in coal,metal,and non-metal mines for the purpose of lifting and ioweing materel andpersonnel in the inclined shafts,also is used as lifting equipment in small shafts.
| 型号规格 Model | 钢绳拉力 | 卷 筒 Wingding Drum | 钢丝绳 Wire cable | 功率 Power | 重量 Weight | |||
| 直径 Diameter | 宽度 Width | 容绳量 Diameter | 直径 Duaneter | 宽度 Width | ||||
| kn | mm | mm | m | mm | mm | kw | kg | |
| JH-5 | 50 | 280 | 230 | 80 | 14 | 4.97-6.9 | 5.5 | 580 |
| JH-8 | 80 | 280 | 260 | 11.5 | 14 | 4.97-6.9 | 7.5 | 600 |
| JHC-14 | 140 | 435 | 260 | 11.5 | 22 | 4.8-6.5 | 15 | 1347 |
| JM-14 | 140 | 400 | 280 | 14 | 22 | 5.65-10.75 | 17 | 2621.5 |
我们要求服务人员时刻关注客户，及时解决设备问题，确保顾客的利益比一切都重要。
