NE型板链高效斗式提升机 High-efficeency chain slat bucket elevator

该类提升机对物料的种类，特性及块度的适用范围广。不仅能提升粉状、粒状和块状普通物料，而且可提升磨琢性较强的物料。

This type of elevators applies to a wide range of types, characteristics, and lumpiness of materials. It can hoist not only common powdery, granular and block materials but also materials with good grindability.

提升机具有NE15～NE800多种规格。提升量范围为15～800m3/h。这类提升机采取流入式喂料，重力诱导式卸料，且采用密集型布置的大容量料斗输送，链速低提升量大。物料提升时，几乎无回料现象，因此驱动功率小，理论计算轴功率是环链提升机的25%～45%。

Such elevators have many specifications, NE15～NE800. The range of their lifting capacity is 15～800m³/h. Such elevators adopt flow-in feeding and gravity-induced discharging model. Besides, they convey materials through intensively arranged hoppers with large capacity. The chain speed is low and lifting capacity is large. When materials are being hoisted, there is nearly no feeding back of materials. Therefore, the drive power is low. According to theoretical calculation, their shaft power is 25%～45% of that of the ring chain elevators.

提升机的喂料采取流入式，材料之间很少发生挤压和碰撞现象，本机的设计保证物料在喂料、提升和卸料中不会撒落，这就防止了磨粒磨损，输送链采用板链式高强度耐磨链条，延长了链条和链斗的使用寿命。

As such elevators adopt flow-in feeding model, there is little extrusion or collision between materials. Elevators of this type are so designed as is able to ensure materials do not fall during feeding, hoisting and discharging, which helps to prevent grain abrasion. High-strength wear-resistant plate chains are used for conveying chains which prolong the service life of chains and chain buckets.

该系列提升机链速低、运行平稳、且采用板链式高强度耐磨链条，因此可达较高的提升高度≤40m。

Elevators of this series have low chain speeds and run smoothly. Besides, they adopt high-strength and wear-resistant plate chains. Thus a large hoisting height (of not larger than 40m) can be reached.

先进的设计原理，保证了整机运行的可靠性，无故障时间超过了3万小时。操作、维修方便，易损件少，与同等提升量的其它各种提升机相比，这种提升机的结构尺寸较小，机壳经折边、焊接，刚性好，外观美观。

Advanced design principle ensures reliable operation of the whole machine. In addition, the duration with no failure exceeds 30,000 hours. Such elevators are easy for operation and maintenance without few easily damaged parts. Compared with other various elevators with the same lifting capacity, elevators of such type feature small structure size, crimped and welded enclosure, good rigidity and attractive appearance.
