PFY硬岩反击式破碎机 Impact crusher for hard rock

国家行业标准JB/T10246

PFY系列反破碎机是我厂在吸收国内外先进技术，结合国内砂石行业具体工矿条件而制的最新一代反击破碎机，该设备具有破碎比大、矿碎后物料呈立方体颗粒、耐磨件使用寿命长等优点，推广使用后为用户取得了明显的经济效益。

PFY impact crushers for hard rock are the newest generation of impact crushers developed by our factory by absorbing advanced technology at home and abroad and according to actual working conditions in domestic sand industry. Such equipment enjoy advantages such as big crushing ratio, the shape of cubic particles of materials after crushing, and long service life of wear-resistant parts. Users of it gain considerable economic benefits.

物料进入机体后碰上高速旋转的锤头迎关打击，大块物料立即被打碎，碎料高速飞向支击板，进行第二次碰撞破碎，反弹物料与后续来的物料相互撞击破碎达到最终破碎目的。

After the materials enter the machine, they bump against the rapidly rotating hammer. As a result, bulk materials are broken into pieces immediately. Then the broken materials fly to the striking plate for the second collision and crushing. The rebounded materials collide with the later-coming materials to realize utter crushing.

型号规格	转子尺寸 Rotor size	给料尺寸 Feeding size	产量 Capacity	出料粒度 Output size	功率 Power	质量 Weight
Model	mm	mm	t/h	mm	kw	t
PFY0504	Φ500×400	30-100	4-10	≤25占85%	22-37	≤2
PFY0607	Φ640×740	30-100	10-20	≤25占85%	22-37	≤4.4
PFY0705	Φ750×500	35-120	10-25	≤25占85%	22-37	≤4.4
PFY0807	Φ850×700	40-150	15-30	≤25占85%	30-55	≤8.9
PFY1007	Φ1000×700	50-200	25-60	≤25占85%	37-90	≤10.5
PFY1010	Φ1000×1000	60-250	30-100	≤25占85%	55-110	≤13.9
PFY1013	Φ1000×1300	80-250	50-120	≤25占85%	110-185	≤14.5
PFY1210	Φ1250×1050	100-300	60-140	≤25占85%	110-185	≤16
PFY1212	Φ1250×1250	100-300	80-160	≤25占85%	132-185	≤21
PFY1214	Φ1250×1400	120-300	80-180	≤25占85%	132-200	≤21.5
PFY1310	Φ1280×1050	120-300	70-150	≤25占85%	132-200	≤19
PFY1315	Φ1300×1500	150-300	100-250	≤25占85%	180-315	≤23
PFY1320	Φ1300×2000	150-350	200-350	≤25占85%	300-400	≤26
PFY1415	Φ1400×1500	200-400	250-400	≤25占85%	300-400	≤26
PFY1622	Φ1600×2200	200-400	400-600	≤25占85%	450-560	≤101
PFY1822	Φ1800×2200	250-500	500-800	≤25占85%	560-710	≤118
