XQ-5嵌样机供实验室将不规则的小块矿样和电木粉混合，热压成形，以便于进行矿样的研磨和鉴定。
XQ-5 embedding sample machine is used in the laboratory to mix irregular small ore samples and bakelite powder as well as thermoform the mixture, to make it easy to grind and identify ore samples.
该机采用手动油压千斤顶加压，通过电热器加热，使小块矿样和电木粉的混合物热压成形。嵌样模外附有散热装置。
This machine uses hand-operated oil jack for pressurization and electric heater for heating, to thermoform the mixture of small ore samples and bakelite powder. The embedding sample mould is equipped with heat radiating device on its outside.
| 嵌样模直径 Embedded-like mode diameter | mm | 32 |
| 嵌样模厚度 Embedded-like mode thiekness | mm | 8～12 |
| 电热器 Heater | 220V、200W | |
| 液压千斤顶额定压力Rated pressure of hydraulic jacks | T | 5 |
| 液压千斤顶最低高度Mininm of hydraulic jacks | mm | 210 |
| 液压千斤顶大行程Large stroke of hydraulic jacks | mm | 116 |
| 压力表 Manometer | kg/cm2 | 0～600 |
| 水银温度计 Mercury thermometer | ℃ | 0～200 |
| 外形尺寸 Overall dimensions | mm | 320×180×615 |
| 重量 Weight | kg | 38 |
