振动筛适用于地质、冶金、燃化、建工、水泥、医院、化工、粉体、国防等科研、院校实验室化验，试验物料筛分分析。
AK、AG型焦炭转鼓机械筛，适用冶金、铁矿、烧结、球团矿等试验筛分，分析。本产品由原地矿部唯一指定企业生产，执行行业标准。
Vibrating Screen is applicable to be used in labs of research institutes and institutions of higher learning in geological, metallurgical, fuel chemical, building engineering, cement, hospital, chemical, powder, national defense and other industries for screening and analysis of test materials.
AK、AG Model Coke Rotary Drum Mechanical Screen is applied to test, screening and analysis of metallurgical and sintered pellets and iron. The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Resources, in compliance with the Industrial standards.
ISO-1605鼓前一次振动筛、二次振动筛适于冶金、铁矿石、烧结矿、球团矿等实验筛分之用。
ISO-1605 Pre-drum Primary and Secondary Vibrating Screen is applied for screening of refractory gold ,iron, sintered, pellet ores and other materials in labs.
| 筛分设备技术参数 Screens | |||||||
| 型号规格 Model |
筛框尺寸Screen size | 筛孔尺寸 Hole size |
层数Number | 给料粒度 Feed size |
处理量capacity | 功率power | 质量 weight |
|---|---|---|---|---|---|---|---|
| mm | mm | mm | t/h | kw | kg | ||
| 3GS500×1000三层振筛机 Three tiers screen |
500×1000 | 6-25 | 3 | ＜80 | ≤10 | 0.75 | 400 |
| AK98型焦炭转鼓机械筛 Machinery screen |
1600×500 | 25-40 | 2 | ＜80 | 3-4 | 980 | |
| AG98型焦炭筛分给合式机械筛 Machinery screen |
25-40 | ＜80 | ＜4 | ||||
| 标准筛 Standard screen |
φ200 | 20-200 （目） |
≤0.5 | ||||
| SHXL500细粒连续振筛机 Fine size continue shake sifting machlng |
Φ500 | 2 | ≥0.064 | 80 | 1.1 | 160 | |
我们要求服务人员时刻关注客户，及时解决设备问题，确保顾客的利益比一切都重要。
