本机为实验室干、湿两用磨样机，结构紧凑新颖，传动简单，胶辊少，磨矿效率高，操作方便、安全可靠。可供冶金、建材、地质、化工和煤炭等实验研究单位及选矿厂进行矿石可选性研究或供其它工业部门磨细少量物料之用。尤其是黄金样品磨细的****理想设备。本产品由原地矿部唯一指定企业生产，执行行业标准。
The machine is dry and wet dual -purpose sample grinding device and features compact and original structure, simple drive, few rubber roller, highly efficient grinding, convenient operation, safety and reliability. It can be used in ore feasibility study for labs and research institutes of metallurgical, building material, geological, chemical and coal industries as well as mineral processing plant or for fine grinding of minor materials in other industries. It is an ideal equipment for fine grinding of gold sample. The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Resources, in compliance with the Industrial standards.
| 筒体容积 Drum volume | L | 1 | 2 |
| 筒体尺寸 Drum size | mm | Φ85×130 | Φ120×180 |
| 磨 矿 量 Capacity | g | 75 ～ 210 | 250 ～ 400 |
| 给料粒度 Feed size | mm | ≤2 | |
| 主动辊子转速 Drum speed | r/min | 165 、 200 | |
| 电机功率 Power | kw | 2.2 | |
| 外形尺寸 Overall dimensions | mm | 2125×740×980 | |
| 重 量 Weight | kg | 200 | |
| 注：筒的数量由客户定，价格另计。 | |||
