试验室FJ型多能浮选机技术参数技术参数 Techn

该机适用于冶金、煤炭、化工、建材、地质、石油等部门的选矿实验室、科研单位对少量矿物进行精选分离及进行连续浮选、还可用于新机型的研究及机型选择试验工作及半工业型试验。该机采用变频技术,叶轮无级调速,数字显示,调整精确,运转可靠。

The machine is suitable to be used in research institutes and mineral processing labs in metallurgical, coal, chemical, building material, geological, petroleum and other industries for separating , cleaning and continuously floating minor samples as well as new machine type research and selection test and semi-commercial test. It introduces frequency conversion technology, stepless speed governing of impeller and digital display with accurate adjustment and reliable operation.

型号规格
Model
容量
Capa.
选槽容积
Volume
叶轮直径
Impeller  diameter
叶轮转速
Impeller speed
给矿粒度
Feed size
功率
Motor power
质量
Weight
g L mm r/min mm w kg
FJ 8组16槽 1.5、3  5、7 Φ73、Φ95  Φ120 ≤2400 ≤0.5 250 500
FJ8 -5升 4组8槽 5 Φ95 ≤2400 ≤0.5 250 250

FJ型多能浮选机 Multi-energy flotation machine

FJ8-5型多能浮选机 Multi-energy flotation machine
