试验室CGKW型智能微电脑控温仪 Technical

用途:该仪器是一种新型的测定煤炭或可燃质灰分含量的专用设备。

特点:将被测试样放在传送链条上,链条将试样送入高温区燃烧,然后传送链再将燃烧后的试样带出高温区,由于试样是缓慢进入高温区的,因此避免了试样的爆燃。另外,传送链速度无级可调,可根据试样的要求改变灰化时间,适用所有煤种。

Use: It is a new type of special equipment for measuring ash contents in coal and combustible materials.

Features: Samples to be tested are put onto the delivery chains where the samples will be sent to the high temperature area for combustion before being removed out of it. The slow access by the samples to the high temperature area prevents the samples from being exploded. In addition, the delivery chains with controllable stepless speed can change ashing time as required by the samples applied to a variety of coals.

炉膛长度 Furnace hearth length mm 730
恒温带长度Constant temperature zone mm 815℃时不小于 150mm,
温差不大于 10℃
no less than 150mm at  815℃ with temperature being no greater than 10℃
最高炉温 Max.furnace temperature 900
升温时间 Temperature rise time min (由室温升至 815℃) 45min
45min(with ambient temperature increase to 815℃)
电源Power supply V AC220V±10%50Hz
****功率Max power KW 4
适应性:各种煤、焦炭及其燃料Applicability: a variety of coal, coke and other fuels

CGKW型智能微电脑控温仪 Intelligent Microcomputer Temperature Control Instrument
