试验室RCT型混合/磁力搅拌器（安全型）技术参数

新一代最为畅销的实验室仪器。New: 强力马达，转速范围广New: 双重温度控制模式用于快速加热介质。

The most popular new-generation laboratory instrument. New: powerful motors with wide speed range; new: dual temperature control mode is for rapid heating of medium

- 内置温度控制系统
- Built-in temperature control system

- 随机附送 PT 1000 温度传感器 (PT 1000.60)
-Temperature sensor model PT 1000 (PT 1000.60) attached

- 通过数显屏可对加热温度和搅拌转速进行精确控制
- Accurate control on heating temperature and stirring speed can be performed through digital display

- 数字显示安全温度设置
- Digital display of safe temperature settings

- 高温警示>> ，提示用户盘面高温，小心烫伤
- High temperature warning prompts user for high temperature and burn

- 错误代码数字显示
- Digital display of error code

- 加热盘安全回路可调 (5-360°C )
- Heating plate safety loop adjustable (5-360℃)

- 安全控制型加热磁力搅拌器，适于无人操作
- Heating magnetic stirrer that can be reliably controlled for unattended operation

- DIN 12878 标准接口，可连接外部温度及精确控温，如： ETS-D5
- DIN 12878 standard interface for connection to external temperature and accurate control temperature, for example ETS-D5

- 先进的热控技术，安全水平高
- Advanced thermal control technology with high level of safety

- 仪器密闭性好，保护等级高(IP 42),使用寿命长
- Outstanding tightness, high protection level (IP42), long service life

- 磁性强
- Strong magnetic

- 随机附送 H 100 保护膜
- Protection film H100 attached

选配件: H 135.3 加热托盘, H 135.313 1/4 加热块，金色，容积 4 ml, H 135.314 1/4 加热块，蓝色，容积 8 ml, H 135.315 1/4 加热块，红色，容积 16 ml, H 135.310 1/4 加热块，黑色，容积 20 ml, H 135.311 1/4 加热块，绿色，容积 30 ml, H 135.312 1/4 加热块，橙色，容积 40 ml, H 135.4 加热套，用于 100 ml 圆底烧瓶, H 135.５ 加热套，用于 500 ml 圆底烧瓶, H 135.６ 加热套，用于 1000 ml圆底烧瓶, H 135.410 加热套内衬，用于 10 ml 圆底烧瓶 (金色), H 135.411 加热套内衬，用于 25ml 圆底烧瓶 (蓝色), H 135.412 加热套内衬，用于 50 ml 圆底烧瓶 (红色), H 135.510 加热套内衬，用于 10 ml 圆底烧瓶 (金色), H 135.511 加热套内衬，用于 25 ml 圆底烧瓶 (蓝色), H 135.512 加热套内衬，用于 300 ml 圆底烧瓶 (红色), H 135.610 加热套内衬，用于 500 ml 圆底烧瓶 (紫色),ETS-D5, ETS-D6, IKAFLON 10 磁力搅拌子, IKAFLON 15 磁力搅拌子, IKAFLON 20 磁力搅拌子, IKAFLON 25 磁力搅拌子, IKAFLON 30 磁力搅拌子, IKAFLON 40 磁力搅拌子,IKAFLON 50 磁力搅拌子, IKAFLON 80 磁力搅拌子, TRIKA 25 三角体磁力搅拌子, TRIKA 42 三角体磁力搅拌子, RS 1 磁力搅拌子套装, RSE 搅拌子移出棒, H 100 保护罩, PT 1000.60 温度传感器, 温度传感器，玻璃覆膜, H 38 固定支杆, H 44 夹头, H 16 V 支杆, H 16.1 延长支杆, H 15 加热锅, H 28 加热锅, H 29 油浴锅, H 30 油浴锅, H11 欧式插头电源线, H11 中式插头电源线, H11 英式插头电源线, H11 美式插头电源线

Options: H 135.3 heating tray; H 135.313 1/4 heating block, golden, vol 4ml; H 135.314 1/4 heating block, blue, vol 8ml; H 135.315 1/4 heating block, red, 16ml; H 135.310 1/4 heating block, black, 20ml, H 135.311 1/4 green, 30ml, H 135.312 1/4 heating block, orange, 40ml; H 135.4 heating jacket for 100ml round bottom flask; H 135.５ heating jacket for 500ml round bottom flask; H 135.６ heating jacket for 1000ml round bottom flask; H 135.410 heating jacket liner for 10ml round bottom flask (golden); H 135.411 heating jacket liner for 25ml round bottom flask (blue); H 135.412 heating jacket liner for 50ml round bottom flask (red); H 135.510 heating jacket liner for 10ml round flask (golden); H 135.511 heating jacket liner for 25ml round bottom flask (blue); H 135.512 heating jacket liner for 300ml round bottom flask (red); H 135.610 heating jacket liner for 500ml round flask (purple); magnetic stirring bar models ETS-D5, ETS-D6 and IKAFLON 10; magnetic stirring bar model IKAFLON 15; magnetic stirring bar model IKAFLON 20; magnetic stirring bar model IKAFLON 25; magnetic stirring bar model IKAFLON 30; magnetic stirring bar model IKAFLON 40; magnetic stirring bar model IKAFLON 50; magnetic stirring bar model IKAFLON 80; triangular magnetic stirring bar model TRIKA 25; triangular magnetic stirring bar model TRIKA 42; magnetic stirring bar kits model RS1; RSE magnetic stirring bar removing rod; H100 protective cover; PT 1000.60 temperature sensor; temperature sensor; glass film; H38 fixing strut; H44 clamp head; H16V strut; H 16.1 extension strut; H15 heating pan; H28 heating pan; H29 oil bath pot; H30 oil bath pot; H11 power cord for European plug; H11 power cord for Chinese plug; H11 power cord for British plug; H11 power cord for US plug

搅拌点位数目

每个搅拌点位****搅拌量 (H2O) Stir each mixing point maximum amount (H2O)		20
单个搅拌点位的转速偏差	%	5
****搅拌量 (H2O) Maximum stirring capacity (H2O)		20
电机输入功率Motor input power	W	16
电机输出功率Motor output power	W	9
转速显示 Speed display		LED
速度范围 Speed range	1/min	50 - 1500
搅拌子****长度 Maximum length of stirring	mm	80
加热输出功率 Heat output power	W	600
加热速度 1升H2O in H 15)	K/min	6.5
加热温度范围Heating temperature range	°C	50 - 310
加热温度控制 Heating temperature control		LED
加热温度控制精确度 Heating temperature control accuracy	±K	1
转速控制 Speed control		无级
可调安全温度回路最小值 Adjustable safety circuit minimum tempera	°C	50
可调安全温度回路****值 Adjustable safety circuit max temperature	°C	360
外接温度传感器接口 External temperature sensor interface		德国工业标准DIN 12 878
带传感器控温精确度 Control accuracy with sensor	±K	1
工作盘材质 Plate material		铝合金
工作盘外形尺寸 Working plate dimensions	mm	135
外形尺寸 Dimensions	mm	160 x 85 x 270
重量 Weight	kg	2.5
允许环境温度 Permissible ambient temperatu	°C	5 - 40
允许相对湿度 Relative humidity allowed	%	80
DIN EN 60529 保护方式 DIN EN 60529 Protection Mode		IP 42
电压 Voltage	V	220 - 230 / 115 / 100
频率 Frequency	Hz	50/60
仪器输入功率 Power input	W	650
