QSY型实验室解析炭再生回转窑适用于金矿选厂炭浆法工艺中将脱水后的解析炭再生处理，综合回收利用，亦适用冶金、化工、地质、矿山、建材、环保部门对物料进行焙烧、烧结、挥发、离析等试验。具有自动控温、节能、效率高等特点。
QSY Lab. Analytical Carbon Regeneration Rotary Kiln is applicable to regeneration treatment and comprehensive recovery and utilization of the dewatered analytical carbon in CIP process for beneficiation plant in gold mines. It also can be used in calcinations, sintering, volatilization, segregation and other tests and features automatic temperature control, energy conservation and high efficiency among others.
| 型号规格 Model | 单位Uite | QSY475 | QSY252 | QSY139 |
| 炉管尺寸 Furnace tube size | mm | Φ400 | Φ219 | Φ133 |
| 物料含水 Water | % | ＜40 | ＜40 | ＜40 |
| 炉管转速Furnace tube speed | r/min | ＜3.5 | ＜3.5 | ＜3.5 |
| 工作温度Temperature | ℃ | ≤700 | ≤810 | ≤810 |
| 筒体倾角 Shall angle | (°) | ＜3 | ＜6 | ＜6 |
| 处理能力 Capacity | kg/h | 30 | 160 | 5.5 |
| 电热功率 Power | kw/v | 81/380 | 36/380 | 18/380 |
